| SKU | Width | Height | Dimensions | Pedestal height | CAD PDF drawings | CAD DWG drawings | CAD DXF drawings | |
|---|---|---|---|---|---|---|---|---|
| 1202-36-9 | 6″ | 108″ | H:2"Lg:144"P:2" | 37″ | DWG | DXF | ||
| 1202-40-9 | 6″ | 108″ | 40 3/8″ | DWG | DXF | |||
| 1202-42-9 | 6″ | 108″ | H:7 1/2"Lg:192"P:1" | 43″ | DWG | DXF | ||
| 1202-36-9-1 | 3″ | 108″ | 37″ | - | - | - | ||
| 1202-40-9-1 | 3″ | 108″ | 40 3/8″ | - | - | - | ||
| 1202-42-9-1 | 3″ | 108″ | H:16″Lg:144″P:1″ | 43″ | - | - | - |
Half Columns are identified by "-1" at the end of the product code.
General Installation Guide
Installation Guide for Columns 1500-C, 1502-C & 1202
| Width | 3″, 6″ |
|---|---|
| Height | 108″ |
| Dimensions | H:16″Lg:144″P:1″, H:2"Lg:144"P:2", H:22″Lg:144″P:3/4″, H:4″Lg:192″P:3/4″, H:7 1/2"Lg:192"P:1", H:7/8"Lg:144"P:2" |
| Pedestal height | 37″, 40 3/8″, 43″ |
| CAD PDF drawings | –, 8179, 8194, 8202 |
| CAD DWG drawings | –, 8181, 8196, 8204 |
| CAD DXF drawings | –, 8183, 8198, 8206 |
